Boiler Water Conditioner
PRODUCT DESCRIPTION
BW Conditioner is a multifunctional, liquid boiler water treatment chemical formulated with
alkaline components, corrosion and scale inhibitors, volatile amines for protection of
condensate system and sludge conditioner.
FEATURES AND BENEFITS
Multipurpose liquid boiler water treatment chemical
Suitable for all boilers up to 30 bar pressure
Volatile amines are present to neutralise acids
Disperses sludge and sediment for efficient blowdown removal
Promotes better heat transfer by keeping boiler tubes clean
Prevents scaling and corrosion, increasing system life and reliability
Simple testing procedure.
USAGE
BW Conditioner is designed for optimum protection of ships boiler systems when used in
conjunction with an oxygen scavenger. The product is formulated to be used with good
quality feed water. It is recommended that the product is dosed continuously with an
automatic dosing unit, but it can be fed into the feed line by using a by-pass feeder pot.
CONTROL
The minimum recommended dosage level is 1.2 litres of BW Conditioner per tonne of boiler
capacity yielding a P-Alkalinity level of 150 ppm ( CaCO3 ). With an untreated system it is
recommended to bring treatment up to a P-Alkalinity level of 200 ppm. The table below
shows the amount of product required to elevate P-Alkalinity to a level of 200 ppm.
P-Alkalinity 0 50 100 150 200 250 300 350
Dose in lt/ton 2.4 1.8 1.2 0.6 0 0 0 Blow
Down
Always refer to the boiler manufacturers specifications and work in conjunction with these.
Typical control limits are: P-Alkalinity 150-300 ppm as CaCO3; Condensate pH 8.5-9.0.
TESTING
A representative sample of boiler water sample should be taken for analysis daily. The
sample should be taken from the same point after blowdown, cooled and tested immediately.
It is important that regular testing is carried out to maintain maximum efficiency in boiler
operation and treatment levels are obviously correct.
